Brand

Display Device

Display System	3 LCD system
Size of effective display area	0.64” (16.3 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of pixels	6,912,000 (1920 × 1200 × 3) pixels

Projection Lens

Focus	Manual
Zoom - Powered/Manual	Manual
Zoom - Ratio	Approx. x 1.45
Lens Shift	Manual
Throw Ratio	1.5:1 to 2.2:1

Light source

Type	Ultra high pressure mercury lamp
Wattage	250 W type
Screen size	40” to 300” (1.02 m to 7.62 m) (measured diagonally)

Light output

Lamp mode: High	4000 lm
Lamp mode: Standard	3200 lm
Lamp mode: Low	2600 lm

Contrast

Contrast ratio (full white / full black)

2500: 1

Speaker

Speaker

12 W x 1 (monaural)

Display resolution

Computer signal input	Maximum display resolution: 1920 × 1200 dots*3
Video signal input	480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i The following items are available for digital signal only; 1080/60p, 1080/50p, 1080/24p

Keystone Correction

Vertical	48 Hz to 92 Hz
Horizontal	19 kHz to 92 kHz

INPUT OUTPUT (Computer/Video/Control)

INPUT A	RGB / Y PB PR input connector: Mini D-sub 15-pin (female) Audio input connector: Stereo mini jack
INPUT B	HDMI input connector: HDMI 19-pin, HDCP support
INPUT C	HDMI input connector: HDMI 19-pin, HDCP support
S VIDEO IN	S-video input connector: Mini DIN 4-pin
VIDEO IN	Video input connector: Phono jack
IO Output	Monitor output connector*4: Mini D-sub 15-pin (female) Audio output connector*5: Stereo mini jack
IO REMOTE	RS-232C connector: D-sub 9-pin (male)
IO LAN	RJ-45,10BASE-T/100BASE-TX
IO USB	Type-A Type-B
MICROPHONE IN	Microphone input: Mini Jack

Acoustic Noise

Lamp mode: Low

29 dB

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	Approx. 406 × 113 × 330.5 mm (15 31/32 × 4 7/16 × 13 inches)
Mass	Approx. 5.7 kg (12 lb)

Others

Projector Power requirements	AC 100 V to 240 V, 3.6 A to 1.6 A, 50/60 Hz
Remote commander	RM-PJ8
Optional Lamp	LMP-C250
Wireless LAN module	IFU-WLM3
