Brand

Display Device

Display System	3 LCD system
Size of effective display area	0.75” (19 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of pixels	3,072,000 (1280x800 x 3) pixels

Projection Lens

Focus	Manual
Zoom - Powered/Manual	Manual
Zoom - Ratio	Approx. x 1.6
Throw Ratio	1.10:1 to 1.79:1

Light source

Type	Ultra high pressure mercury lamp
Wattage	225 W type
Screen size	30" to 300"(0.76 m to 7.62 m) (measured diagonally)

Light output

Lamp mode: High	4200lm
Lamp mode: Standard	3200lm
Lamp mode: Low	2500lm

Contrast

Contrast ratio (full white / full black)

3700:01:00

Speaker

Speaker

16 W (monaural)

Display resolution

Computer signal input	Maiximum display resolution: 1600 x 1200 dots *4
Video signal input	NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 575/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p

Keystone Correction

Vertical

+/- 20°

INPUT OUTPUT (Computer/Video/Control)

INPUT A	RGB / Y PB PR input connector: Mini D-sub 15-pin (female) Audio input connector: Stereo mini jack
INPUT B	RGB input connector: Mini D-sub 15-pin (female) Audio input connector: Stereo mini jack
INPUT C	HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support
INPUT D	HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support
S VIDEO IN	S video input connector: Mini DIN 4-pin
VIDEO IN	Video input connector: Phono jack
IO Output	MONITOR output connector *5: Mini D-sub 15-pin (female) Audio output connector *6: Stereo mini
IO REMOTE	RS-232C connector: D-sub 9-pin (male)
IO LAN	RJ-45, 10BASE-T/100BASE-Tx
IO USB	Type-A Type-B
MICROPHONE IN	Microphone input: Mini Jack

Acoustic Noise

Lamp mode: Low

29dB

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	Aprox. 365 x 96.2 x 252 mm (14 3/8 x3 25/32 x9 29/32 " )
Mass	Approx. 4.1 kg (9 lb)

Others

Projector Power requirements	AC 100 V to 240 V, 3.4 A to 1.5 A, 50 Hz / 60 Hz
Remote commander	RM-PJ8
Optional Lamp	LMP-E221
Wireless LAN module	IFU-WLM3
