Brand

Display Device

Display System	3 LCD system
Size of effective display area	0.76” (19.3 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
Number of pixels	6,912,000 (1920 x 1200 x 3) pixels

Projection Lens

Focus	Manual
Zoom - Powered/Manual	Manual
Zoom - Ratio	Approx. x 1.45
Lens Shift	Manual
Throw Ratio	1.28:1 to 1.88:1

Light source

Type	Laser diode
Screen size	40" to 300" (1.02 m to 7.62 m)

Light output

Lamp mode: Standard

5000lm

Contrast

Contrast ratio (full white / full black)

500,000:1

Speaker

Speaker

16 W (monaural)

Keystone Correction

Vertical	48 Hz to 92 Hz
Horizontal	15 kHz to 92 kHz

INPUT OUTPUT (Computer/Video/Control)

INPUT A	RGB / Y PB PR input connector:Mini D-sub 15 pin (female) Audio input connector: Stereo mini jack
INPUT B	HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support
INPUT C	HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support
INPUT D	HDBaseT interface connector: RJ45, 4 play (Video, Audio, LAN, Cont rol)
VIDEO IN	Video input connector: BNC Audio input connector: Shared with INPUT A
IO Output	Audio output connector: Stereo mini jack
IO REMOTE	D-sub 9-pin (male) / RS232C
IO LAN	RJ45, 100BASE-TX (Shared with INPUT D)
IO USB	Type-A, Type-B

Dimension and Mass

Dimensions (W x H x D) (without protrusions)	510 x 113 x 354.6 mm (20 3/32 x 4 7/16 x 13 31/32 inches)
Mass	Approx. 8.7kg (19 lb)
